3 in 1 Integrated Concrete Machine

INTEGRATED CONCRETE MACHINE

0 – 7.5 m³
Output per Hour

125m ~ 250m
Pump Range

50 – 60Hz
Elecrical Powered

3 MINUTES
Auto Batching

RBM Foam Concrete Machine

RBM 3 in 1 Foam Concrete Machine Model: RBM-2000 (Patent Granted: MY-133290-A, MY-149328-A, MY-187368-A) is a multi-function device integrated with smart & innovative technologies to meet building requirements in a green, systematic, and energy-efficient manner. The new integrated lightweight concrete machine is equipped with a smart operation system for producing various types of concrete for building applications with high performance and quality control. As a result, this machine reduces construction costs, saves time and labour, and increases efficiency. The machine is built with a RBM foam concrete generator with a great capacity that generates 600 litres of foam per minute. There is also a conveyor to deliver raw materials for processing concrete. The RBM-2000 has a unique design with an auto-weighing scaling system to automatically control all the material required according to the formulation set. Additionally, the RBM-2000 has a powerful mixer that meets different types of RBM foam concrete mixing and a high-tech pumping system that delivers fresh concrete in the shortest amount of time.
Highlights

COMPACT DESIGN

3 IN 1 PORTABLE FEATURES

PATENT GRANTED

NEW POWERFUL PUMP ENGINE

Advantages

COMPACT DESIGN

Multi – function

The design of the lightweight concrete machine is integrated with batching-plant, ready mix truck and mobile crane features into this machine.
Formwork System
INTEGRATED CONCRETE MACHINE

ONE-STOP CONCRETE STATION

Smart Operation System

The foam concrete machine is built in with auto batching system which allow the raw material to mix within 3minutes and ready to delivery to a 125m -250m distance range with high quality consistency

MOBILIZATION

Portable & Convenient

It is built with a lightweight design and able to set-up at anywhere & work at anytime. This help to increase the work performance

INTEGRATED CONCRETE MACHINE
INTEGRATED CONCRETE MACHINE

QUALITY GUARANTEE

Precession & Accuracy

SMALL NUMBER OF WORKERS
Minimum workers are 3 people The machine able to quality control every material input into the mix of concrete. It can design any type of concrete strength from Grade 5 to Grade 35 with consistency

PUMP SYSTEM

Reduce Wastage

All the concrete mixture will be pumped out without any wastage and the concrete piping is easily clean

INTEGRATED CONCRETE MACHINE
INTEGRATED CONCRETE MACHINE

HIGH PERFORMANCE

Easy Operation

The control panel allow the operator to start the machine easily and deliver the concrete of 7.5m3 per hour

Gallery

Specification

Concrete Mixer : 4kW, 380V – 415V, 50Hz
High Tech Pumpung System : 7.5kW, 380V – 415V, 50Hz
Conveyor :0.75kW, 380V – 425V, 50Hz
Speed Range : 40rpm – 80rpm
Concrete Output :0 – 7.5m³/hr
Pumping Distance :125m vertical, 250m horizontal
Pump System :Engine Cooling System, Grease Oil
Mixer :Safety Cover, Dust Control sheet
Foam Generator :Pressure Gauge, Electrical Valve, Safety Valve
Foldable Conveyor :Protection Cover
Filtering Board :Filter Particles, ∅ 8mm
(All above component built in with overload jump switch)
Mixer Tank Volume :650litres
Hopper Tank Volume :650L
Foam Generator Volume :400L
Air Compressor Volume :300L
Operating Air Pressure :6 bar
Foam Output :600Liters/min
Belt :High Stress Rubber
Width, Length :0.35m, 7.00m
Overall Length :2.50m
Overall Width :1.50m
Overall Heigth :1.66m
Overall Weight :980kg
